Automatic Dishwasher Machine
>
|
|
| Place of Origin | China |
| Brand Name | HENGZE |
| Certification | CE |
| Model Number | HZ-203E |
High Pressure 380V Automatic Dishwasher Machine
Quick Details
| Water Tank Capacity(L) | 75 |
| Power Line Specifications(mm) | 25 |
| Water Inlet(DN) | 20 |
| Drainage(DN) | 50 |
| Water Pressure(MPa) | 0.1 ～ 0.35 |
| Water Main Wash Temperature(℃) | 55-65 |
| Water Rinse Temperature(℃) | 82~90 |
| Water Inlet Temperature(℃) | 10~60 |
| Minimum Water Flow(L/H) | 405 |
| Exhaust Inlet(m3/min) | 5.7 |
| Exhaust Outlet(m3/min) | 11.3 |
1 Applicable to social catering, staff canteen and other venues;
2 Compact structure, saving operating space;
3 Clear operation panel, mechanical buttons and LED digital temperature display;
4 Uniquely designed 8-shaped concave anti-blocking nozzle, equipped with 9 washing arms, the cleaning effect is better;
5 Good temperature control function, ensure the cleaning temperature is 55°C, and the spraying temperature is above 82°C, to achieve better cleaning effect;
6. The adjustment of the water inlet pressure regulating valve is simpler, and the water inlet pressure of the machine can be adjusted quickly;
7. Fully automatic water injection and replenishment, automatic control of water level to prevent dry burning;
8 The cleaning arm and spray arm are easy to disassemble and clean, no auxiliary tools are needed, and the maintenance work is simpler;
9 The cleaning cylinder is equipped with an overflow pipe, which has an automatic overflow function, and the drainage operation is simpler;
10 The IRON-MAX system has a 120° fan-shaped water spray range and a precise water spray pattern to keep the tableware at the best angle for rinsing, so that each tableware in the basket can be evenly and completely rinsed;
Specifications:
| Model No | 203E |
| Product Name | Rack Conveyor Dishwasher |
| Performance | |
| External Dimension(mm) | |
| Length×Width×Height | 1105x772x1650 |
| Electrial | |
| Rated Voltage(V/N/Hz) | 380/3/50 |
| Rated Power (kW) | 43.75 |
| Electric Current(A) | 66.5 |
| Main Heating Power(kW) | 12 |
| Main Wash Pump Power(kW) | 1.5 |
| Rinse Heating Power(kW) | 30 |
| Configuration | |
| Water Tank Capacity(L) | 75 |
| Power Line Specifications(mm) | 25 |
| Water Inlet(DN) | 20 |
| Drainage(DN) | 50 |
| Water Pressure(MPa) | 0.1 ～ 0.35 |
| Water Main Wash Temperature(℃) | 55-65 |
| Water Rinse Temperature(℃) | 82~90 |
| Water Inlet Temperature(℃) | 10~60 |
| Minimum Water Flow(L/H) | 405 |
| Exhaust Inlet(m3/min) | 5.7 |
| Exhaust Outlet(m3/min) | 11.3 |
| Packing Size(mm) | 1215*850*1770 |
| Net Weight(kg) | 218 |
| Gross Weight(kg) | 280 |
