Automatic Dishwasher Machine
>
|
|
| Place of Origin | China |
| Brand Name | HENGZE |
| Certification | CE |
| Model Number | HZ-4100 |
Hotel Kitchen Equipment Commercial Flight Type Automatic Dishwashe Machine
Place of Origin:Guangdong, China
Brand Name:HENGZE
Housing Material:Stainless steel
Warranty:1 Year
Type:Freestanding
Application:Commercial, Commercial
Power Source:Electric
App-Controlled:Yes
Product name:Hotel Kitchen Equipment Commercial Flight Type Dishwasher
Material:304 Stainless Steel
Dishwasher Type:Commercial Dishwasher Machine
Certification:CE
Voltage:380V/50Hz/3P
Control Type:Semi-Integrated
Color:Stainless Steel Silver
Function:Strong Dish Washing
Technical Advantages and Characteristics of Flight Type Dishwasher
1 The inlet end is equipped with a drawer type slag receiving and filtering device, and the filter screen can also be taken out in time for cleaning during the operation of the machine.
2 The side of the electrical box panel is equipped with an emergency stop switch to facilitate the operator to stop the operation of the machine in an emergency.
3 The chain conveyor adopts engineering plastic mesh claws with high
temperature resistance,corrosion resistance,sanitation and non toxicity, which has wide applicability.
4 Double rinsing system ensures washing effect.
5 It can be equipped with efficient pre-washing and drying system to improve the hygienic standard of tableware.
6 The drive motor overload devicecan stop operation in time in case of overload to prevent damage to the machine and tableware.
7 A limit switch is installed at the outlet end to prevent damage caused by tableware not unloaded in time.
8 Flexible modular combination design and appropriate functional
modules can be selected according to the space size of the site.
9 Fully enclosed bottom plate with insect and rat proof design
| ModelNo | P | A | R | D |
| Product Name | Pre-washing | Main -washing | Rinsing | Drying |
| Length | 800 | 800 | 600 | 800 |
| Width | 862 | 862 | 862 | 862 |
| Hsmt | 1426 | 1426 | 1426 | 2000 |
| Electrial | ||||
| Rated Voltagg(V/Hz) | 380/50 | 380/50 | 380/50 | 380/50 |
| Main Heating Power(kN) | 18 | |||
| Main Wash Pump Power(kW) | 1.5 | 1.5 | ||
| Rinse Heating Power(kW) | 30 | |||
| Rinse Pump Power(kw) | 0.37 | |||
| Water Tank Capacity(L) | 98 | 98 | 24 | |
| WaterInlet(DN) | 3/4°- φ10 | |||
| Drainage(DN) | 50 | 50 | 50 | |
| Water Pressure(MPa) | 0.1～0.35 | |||
| Main Wash Temperature | 55-65 | |||
| Water Rinse Temperature(℃) | 82～ 90 | |||
| WaterInlet Temperature CC) | 10～60 | |||
| Enter Water Hardness(Mg/L) | 34～103 | |||
| Max capacity (rack /hour) PBRDD量 | 7700pcs/H(8inch) | |||
| DryingHeatingPower (kW) | 9 | |||
| DryingPower (kW) | 0.75 | |||
| Drying Temperature (℃) | 55～85 | |||
About Us:
Guangdong Hengze Commercial Kitchen Equipment Co., Ltd.. was established in 2016 and located in Shunde Foshan, China. It is a leading enterprise in the commercial dishwasher equipment industry with strong technical strength and complete production lines.
We are a professional manufacturer specialized in commercial dishwasher equipment with many years experiences. Now we have 4 main dishwasher products including hood type dishwasher, rack conveyor dishwasher and Long line conveyor dishwasher,Bubble Washing Machine . High quality is the most important point for us to make sure our final customers have perfect satisfied using experience. By now, we have cooperated with many Hotels, Schools, Company groups, Hospitals and Restaurants also we have exported our dishwasher into many countries out of China rely on the advantage of our competitive price, high quality, fast producing and delivery.
Hengze has been committed to providing international standard quality commercial dishwasher products and one-stop solutions for all partners. We have the most advanced laser cutting machine, bending machine. From product development to production inspection, we have a complete set of quality control process. Also we have obtained CE ISO14001 ISO9001 certification. Selling well in all cities and provinces around China, the products are also exported to customers all of the world as the United States, Japan, Malaysia, Thailand, Singapore, Qatar, India, Africa, Kazakhstan and Saudi Arabia.
We have an experienced products development team making sure to provide OEM/ODM service with high-quality. Whether selecting a current product from our catalog or seeking engineering assistance for your requirement you can talk to our customer service center about your sourcing requirements. We must provide you professional services with nice price, high quality and fast delivery.
