Rack Conveyor Dishwasher
>
|
|
| Place of Origin | China |
| Brand Name | HENGZE |
| Certification | CE |
| Model Number | HZ-60AS |
High Power Industrial Custom Integrated Rack Conveyor Dishwashers
Quick Details
After-sales Service Provided: Free spare parts Warranty: 1 Year
Application: Hotel, Commercial Power Source: Electric
App-Controlled: NO Private Mold: NO
Control Type:Semi-Integrated Style:Traditional
Housing Material:Stainless steel Inner Material:Stainless steel
Main Features:
1 Up and down rotary washing and rinsing, all-round coverage of dishes to ensure the cleaning effect
2 Adopting highly intelligent and precise control technology, energy consumption is 20-30% less than traditional ones
3 Push-button operation panel
4 Unique laminated door design, both heat preservation and heat insulation, can effectively reduce noise
5 The whole machine is made of S.S. 304, and all the spare parts are made of high quality products. High efficiency Italian water pump to ensure washing power
6 Fully enclosed base plate, insect and rodent proof design
7 Reasonable and compact size to ensure the washing effect while minimizing the space occupied in the kitchen
8 Large LCD operation panel, simple to operate
9 With energy-saving module (patented technology), using the waste heat recovery function, saving energy consumption by 14%
10 Equipped with emergency stop switch, convenient for the operator to stop the operation of the machine in an emergency
Specifications:
| Rated Voltage(V/N/Hz) | 380/3/50 |
| Rated Power(kW) | 5.73 |
| Electric Current(A) | 8.7 |
| Main Heating Power(kW) | 3 |
| Main Wash Pump Power(kW) | 0.73 |
| Rinse Heating Power(kW) | 5 |
| Rinse Pump Power(kW) | 0.15 |
| Water Tank Capacity(L) | 25 |
| Heat Tank Capadity(L) | 10 |
| Power Line Specifications(mm2) | 4 |
| PowerLine Length(m) | 3 |
| Water lnlet(DN | 20 |
| Drainage(DN) | 32 |
| Water Pressure(MPa) | 0.15-0.35 |
| Water MainWash Temperature(°C) | 55-65 |
| Water Rinse Temperature(C) | 82-90 |
| Water Inlet Temperature(C) | 20-60 |
| Enter Water Hardness(Mg/L) | 34~103 |
| Minimum Water Flow(L/H) | 150 |
| Washing Cyle | 60/90/120 |
| Packing Size(mm) | 840*770"1560 |
| Net Weight(kg) | 123 |
| Gros5Weight(kg | 133 |
About Us:
Guangdong Hengze Commercial Kitchen Equipment Co., Ltd.. was established in 2016 and located in Shunde Foshan, China. It is a leading enterprise in the commercial dishwasher equipment industry with strong technical strength and complete production lines.
We are a professional manufacturer specialized in commercial dishwasher equipment with many years experiences. Now we have 4 main dishwasher products including hood type dishwasher, rack conveyor dishwasher and Long line conveyor dishwasher,Bubble Washing Machine . High quality is the most important point for us to make sure our final customers have perfect satisfied using experience. By now, we have cooperated with many Hotels, Schools, Company groups, Hospitals and Restaurants also we have exported our dishwasher into many countries out of China rely on the advantage of our competitive price, high quality, fast producing and delivery.
Hengze has been committed to providing international standard quality commercial dishwasher products and one-stop solutions for all partners. We have the most advanced laser cutting machine, bending machine. From product development to production inspection, we have a complete set of quality control process. Also we have obtained CE ISO14001 ISO9001 certification. Selling well in all cities and provinces around China, the products are also exported to customers all of the world as the United States, Japan, Malaysia, Thailand, Singapore, Qatar, India, Africa, Kazakhstan and Saudi Arabia.
We have an experienced products development team making sure to provide OEM/ODM service with high-quality. Whether selecting a current product from our catalog or seeking engineering assistance for your requirement you can talk to our customer service center about your sourcing requirements. We must provide you professional services with nice price, high quality and fast delivery.
