Rack Conveyor Dishwasher
>
|
|
| Place of Origin | China |
| Brand Name | HENGZE |
| Certification | CE/ISO |
| Model Number | HZ-60AS |
60~75℃ Industrial Kitchen Dishwasher / High Temperature Dispenser Inside Hood Type Rack Conveyor Dishwasher
| Material: | Stainless Steel | Usage: | Hotel/Restaurants/Commercial |
|---|---|---|---|
| Power: | 380/3/50 | Rinse Heating Power(kW) | 5KW |
| Rinse Tank: | 9L | Rinse: | 82-95℃ |
| High Light: |
hood type dishwashing machine,energy saving dishwasher |
||
Features:
1. Special wash pump : Ensuring consistent wash water volume and detergent use, cost control made easy
2. Unique rinse arms design: Flexible top and bottom rinse arms covering all angles enhancing wash performance.Unique rinse arm and nozzle design resulting in better cleaning
3. Excellent rinse temperature control system: Rinse temperature for every wash reaching between 82～95℃
4. Payment Term
40% deposit by T/T payment for start production, 60% by T/T
Small amount by T/T or Western Union are acceptable.
5. Our dishwashers are good for big and small hotels, coffee shops, chain-restaurants and dining halls etc.
Specifications:
| Model No | HZ-60AS |
| ProductName | Hood Dishwasher |
| Heating Characteristics | Intelligent section heating |
| Lengthxwidth×Height | 835x715x1440 |
| Rated Voltage(V/N/Hz) | 380/3/50 |
| Rated Power(kW) | 5.73 |
| Electric Current(A) | 8.7 |
| Main Heating Power(kW) | 3 |
| Main Wash Pump Power(kW) | 0.73 |
| Rinse Heating Power(kW) | 5 |
| Rinse Pump Power(kW) | 0.15 |
| Water Tank Capacity(L) | 25 |
| Heat Tank Capadity(L) | 10 |
| Power Line Specifications(mm2) | 4 |
| PowerLine Length(m) | 3 |
| Water lnlet(DN | 20 |
| Drainage(DN) | 32 |
| Water Pressure(MPa) | 0.15-0.35 |
| Water MainWash Temperature(°C) | 55-65 |
| Water Rinse Temperature(C) | 82-90 |
| Water Inlet Temperature(C) | 20-60 |
| Enter Water Hardness(Mg/L) | 34~103 |
| Minimum Water Flow(L/H) | 150 |
| Washing Cyle | 60/90/120 |
| Packing Size(mm) | 840*770"1560 |
| Net Weight(kg) | 123 |
| Gros5Weight(kg | 133 |
Our Dishwasher Advantages:
1. More than 1,000 large-scale sites (hotels, restaurants, canteens, offices)
2. Clutch rotation system, failure stop, independent emergency stop device
3. 2 speed, to meet all kinds of washing requirements
4. Photoelectric induction detection conveyor belt, cutlery into the machine, the device automatically starts, automatic energy saving
5. original pump and motor.
6. Any environment can guarantee high temperature above 82 ℃ spray
7. structure door, reduce labor, user-friendly design
8. The whole machine is made of SS304 stainless steel,.Pass the European CE, ROHS certification, Hong Kong Food ring office verification
