Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher
  • Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher
  • Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher
  • Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher

Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher

Place of Origin China
Brand Name HENGZE
Certification CE
Model Number HZ-2400
Product Details
After-sales Service Provided::
1 Year
Power Source::
Electric
App-Controlled::
In Optional
Private Mold::
No
Housing Material::
Housing Material:
Function::
Cleaning And Disinfection
Name:
Cleaning And Disinfection
Application Fields::
Standard Wooden Case
Application::
Huangpu ,Guangzhou ,China
Extemal Dimension(mm):
2400x860x1640
Rated Voltage (V/N/Hz):
380/3/50
Rated Power(kW):
31.87
Packing::
Standard Wooden Case
Product Description
Model No HZ2400
ProductName Conveyor Type Small Long Dragon Dishwasher
Performance
Extemal Dimension(mm)
Length×Width×Height 2400x860x1640
Electrial
Rated voltage (V/N/Hz) 380/3/50
Rated Power(kW) 31.87
Electric Current(Al 48
Main Heating Power(kW) 12
Main WashPump Power(kW) 1.5
Rinse Heating Power(kW) 18
Configuration
Water Tank Capacity(L) 92
PowerLine Spedfications(mm2) 10
Water Inlet(DN) 20
Drainage(DN) 50
Water Pressure(MPa) 0.1-0.35
Water MainWash Temperature(°C) 55-65
Water Rinse Temperature(℃) 82-90
Water Inlet Temperature(C) 10-60
Washing
Capacity(rack/hour) 6400pcsper hour 8 inch



Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher 0



Features
● The main washing temperature is above 55°C, and the spraying temperature is above 82°C, in line with the national standard for disinfection and sanitation of food (drink) utensils;
● Compact structure, saving operating space;
● Built-in heat recovery system, energy saving and high efficiency;
● Stable control system, simple mechanical operation panel, with LED temperature display, alarm prompt and fault diagnosis;
● Inclined crawler tracks to maintain the best cleaning angle for tableware;
● Equipped with 8 concave anti-clogging nozzle washing arms to ensure a larger range of fan-shaped water flow and better cleaning performance;
● The washing arm and spraying arm adopt a pull-out structure, which is more convenient to disassemble and clean;
● Import and export double gear design, reduce chain wear;
● Equipped with emergency stop switch, overload automatic shutdown, door open shutdown protection, safe and efficient;

Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher 1Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher 2Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher 3Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher 4Restaurant Hotel Automatic Conveyor Type Small Long Dragon Dishwasher 5
