12KW Commercial Dishwasher Machine Undercounter Coffee Cup Washing Machine
  • 12KW Commercial Dishwasher Machine Undercounter Coffee Cup Washing Machine

12KW Commercial Dishwasher Machine Undercounter Coffee Cup Washing Machine

Place of Origin China
Brand Name HENGZE
Certification CE
Model Number HZ-40E
Product Details
Product Name:
Undercounter Dishwasher
Washing Capacity:
60 Frames/H
Brand:
HENGZE
Material:
304/201 SS
Name:
Commercial Dishwasher Machine
OEM/ODM:
YES
High Light:

12KW Commercial Dishwasher Machine

,

Commercial Dishwasher Machine Undercounter

,

Undercounter Coffee Cup Washing Machine

Product Description

Commercial Dishwashing Machine Smart Coffee Shop Automatic Cup Washing Machine



Quick Details :



voltage&Power
380V/12KW
dimension
600*680*850mm
Gross Weight
80KG/PCS
washing capacity
60 frames/H
water consumption
2.8L/H
main temperature
60-65℃
rinse temperature
80-90℃
Inlet water pressure (kg/C㎡)
2-5kg/C㎡
Inlet size
G1/2"
drain size
θ50
washing basket inlet size
500*400mm





Features:



1 control panel ( three working hours in optional )
2 easy to operate handrail suitable height .labore saving
3 strong washing system (Top +bottom sprayer ,360°no dead angle ,strong oil removal
4 stamping fillet tank (stainless steel material ,rounded smooth hand guard easy to clean
5 inlet and outlet locat under the machine ,copper .durable and not easy to rust
6 Basket -suitable for all kinds of tableware ,dishes ,cups ,glasses



Specification

Model No 40E
Product Name Undercounter Dishwasher
Length×Width×Height 570x620x796
Rated voltage 220V |380V/50Hz/3P
Rated Power 5.9/7.4
Washingheating power 1/1
Rinsing heating power 4.5/6
Washing pump power 0.37
Washing temperature(℃) 55~65
Rinsing temperature(℃) 80~90
Water consumption(L/Basket) 2.3
Capacity(rack/hour) 50Basket/Hour
Installation requirements
Switch(A) ≥32 | ≥25(With leakage protection)
Drainage pipe diameter φ40
Inlet pressure(MPa) 0.15~0.6
Inlet water temperature(℃) 10~60
Inlet hardness(mg/L) ≤50



About Us:





Guangdong Hengze Commercial Kitchen Equipment Co., Ltd.. was established in 2016 and located in Shunde Foshan, China. It is a leading enterprise in the commercial dishwasher equipment industry with strong technical strength and complete production lines.

We are a professional manufacturer specialized in commercial dishwasher equipment with many years experiences. Now we have 4 main dishwasher products including hood type dishwasher, rack conveyor dishwasher and Long line conveyor dishwasher,Bubble Washing Machine . High quality is the most important point for us to make sure our final customers have perfect satisfied using experience. By now, we have cooperated with many Hotels, Schools, Company groups, Hospitals and Restaurants also we have exported our dishwasher into many countries out of China rely on the advantage of our competitive price, high quality, fast producing and delivery.

Hengze has been committed to providing international standard quality commercial dishwasher products and one-stop solutions for all partners. We have the most advanced laser cutting machine, bending machine. From product development to production inspection, we have a complete set of quality control process. Also we have obtained CE ISO14001 ISO9001 certification. Selling well in all cities and provinces around China, the products are also exported to customers all of the world as the United States, Japan, Malaysia, Thailand, Singapore, Qatar, India, Africa, Kazakhstan and Saudi Arabia.

We have an experienced products development team making sure to provide OEM/ODM service with high-quality. Whether selecting a current product from our catalog or seeking engineering assistance for your requirement you can talk to our customer service center about your sourcing requirements. We must provide you professional services with nice price, high quality and fast delivery.
