Automatic Commercial Semi Integrated Dishwasher Traditional Style
  • Automatic Commercial Semi Integrated Dishwasher Traditional Style
  • Automatic Commercial Semi Integrated Dishwasher Traditional Style

Automatic Commercial Semi Integrated Dishwasher Traditional Style

Place of Origin China
Brand Name HENGZE
Certification CE
Model Number HZ-2400
Product Details
Place Of Origin::
Guangdong China
Function::
Strong Dish Washing
Packing::
Standard Wooden Case
Payment Term:
T/T Or Western Union
High Light:

Automatic Semi Integrated Dishwasher

,

Commercial Semi Integrated Dishwasher

,

Commercial Integrated Dishwasher Traditional

Product Description
Commercial Automatic Industrial Dish Washing Machine



Quick Details :

After-sales Service Provided:Free spare partsKeyword:Commercial Belt Conveyor Dishwasher MachineMaterial:304 Stainless Steel
Warranty:1 YearControl Type:Semi-IntegratedDishwasher Type:Commercial Flight Type Dishwasher Machine
Application:CommercialStyle:TraditionalCertification:ISO9001 CE HACCP
Power Source:ElectricHousing Material:Stainless steelVoltage:380V/50Hz/3P
App-Controlled:NOInner Material:Stainless steelColor:Stainless Steel Silver
Private Mold:NOVoltage (V):380Function:Strong Dish Washing
Type:FreestandingProduct name:Large Commercial Automatic Conveyor Dishwasher with DryerAdvantage:Save Electricity,Professional Service,Efficient

Modular Combination Advantages of Flight Type Dishwasher

1 The entry length can be flexibly selected according to the basket, site restriction, washing speed and the speed of placing the tableware;
2 The exit length can be flexibly selected according to the requirements of basket, site restriction, washing speed and drying;
3 Pre-washing, primary washing, drying and neutral sections can be combined according to washing amount, washing speed and tableware type;
4 Electric heating and steam heating are optional for easy use (steam heating is only recommended in places with excess steam)
5 Heater power can be selected according to inlet water temperature;
6 Conveyor belt speed can be adjusted according to the required washing time.


Production Details:


Model No203E
Product NameRack Conveyor Dishwasher
Performance
External Dimension(mm)
Length×Width×Height1105x772x1650
Electrial
Rated Voltage(V/N/Hz)380/3/50
Rated Power (kW)43.75
Electric Current(A)66.5
Main Heating Power(kW)12
Main Wash Pump Power(kW)1.5
Rinse Heating Power(kW)30
Configuration
Water Tank Capacity(L)75
Power Line Specifications(mm)25
Water Inlet(DN)20
Drainage(DN)50
Water Pressure(MPa)0.1 ~ 0.35
Water Main Wash Temperature(℃)55-65
Water Rinse Temperature(℃)82~90
Water Inlet Temperature(℃)10~60
Minimum Water Flow(L/H)405
Exhaust Inlet(m3/min)5.7
Exhaust Outlet(m3/min)11.3
Packing Size(mm)1215*850*1770
Net Weight(kg)218
Gross Weight(kg)280
